Datalogic Magellan 800i Product Reference Guide

Enter/Exit Programming Mode Add-ons
72 Magellan™ 800i Scanner
Add-ons
Add-ons (or supplemental characters) are commonly added to the end of UPC/
EAN bar codes. The scanner will read the add-ons if they are enabled and in the
field of view. Three add-on types are supported: 2-digit, 5-digit and Code 128
add-ons. Supported options are:
None — This option directs the scanner to ignore add-on portion of a UPC/EAN
bar code but still read the main portion of the bar code.
2 Digits — The scanner will optionally read 2-digit add-ons with the UPC/EAN
label.
5 Digits — The scanner will optionally read 5-digit add-ons with the UPC/EAN
label.
Code 128 Add-on — The scanner will optionally read Code 128 add-ons with the
UPC/EAN label.
NOTE
051000(CR)
Contact Customer Support for advanced programming of
optional and conditional add-ons.
Disable Optional 2-Digit Add-ons
DEFAULT
Enable Optional 2-Digit Add-ons
051001(CR)
051100(CR)
Disable Optional 5-Digit Add-ons
DEFAULT

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
