Datalogic Magellan 800i Product Reference Guide

Product Reference Guide 151
Appendix E
USB Keyboard Function Key Mappings
USB Function Key Usage Map
ASCII Key value Usage Name
Modifier/
Scancode
00 NUL ALT right Make 40h 00h
01 SOH ALT right Break 00h 00h
02 STX F11 00h 44h
03 ETX F12 00h 45h
04 EOT GUI right Make 80h 00h
05 ENQ GUI right Break 00h 00h
06 ACK CTRL right Make 10h 00h
07 BEL CTRL right Break 00h 00h
08 BS BS 00h 2Ah
09 HT TAB right 00h 2Bh
0A LF RIGHT arrow (inner keypad) 00h 4Fh
0B VT TAB left 02h 2Bh
0C FF Enter (right keypad) 00h 58h
0D CR CR 00h 28h
0E SO INSERT (inner keypad) 00h 49h
0F SI PAGE UP (inner keypad) 00h 4Bh
10 DLE PAGE DOWN (inner keypad) 00h 4Eh
11 DC1 HOME (inner keypad) 00h 4Ah
12 DC2 LEFT arrow (inner keypad) 00h 50h
13 DC3 DOWN arrow (inner keypad) 00h 51h
14 DC4 UP arrow (inner keypad) 00h 52h
15 NAK F6 00h 3Fh
16 SYN F1 00h 3Ah
17 ETB F2 00h 3Bh
18 CAN F3 00h 3Ch
19 EM F4 00h 3Dh
1A SUB F5 00h 3Eh
1B ESC ESC 00h 29h
1C FS F7 00h 40h
1D GS F8 00h 41h
1E RS F9 00h 42h
1F US F10 00h 43h

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
