Enter/Exit Programming Mode
Product Reference Guide
65
Minimum Reads
This feature specifies the minimum number of consecutive times a UPC-E label
must be decoded before it is accepted as good read.
006201(CR)
Minimum = 1 Read
Minimum = 2 Reads
DEFAULT
006202(CR)
006203(CR)
Minimum = 3 Reads
Minimum = 4 Reads
006204(CR)
GTIN
The following options apply to the GTIN label data format.
Expand UPC/EAN to GTIN
Enables conversion of UPC-E, UPC-A, EAN8, and EAN13 labels into 14 character
GTIN. If add-on information is present on the base label prior to the conversion
taking place, the addon information will be appended to the converted GTIN
label.
051500(CR)
Don’t Expand to GTIN
DEFAULT
Expand to GTIN
051501(CR)
