Enter/Exit Programming Mode EAN-8/JAN-8
68 Magellan™ 800i Scanner
EAN-8/JAN-8
The following options apply to the EAN-8/JAN-8 symbology.
Disable/Enable EAN-8/JAN-8
Enables/disables ability of scanner to decode EAN/JAN-8 labels.
02D200(CR)
Disable EAN-8
Enable EAN-8
DEFAULT
02D201(CR)
Check Digit Transmission
Enable this option to transmit the check Digit along with EAN-8/JAN-8 bar code
data.
00B800(CR)
Don’t Send Check Digit
Send Check Digit
DEFAULT
00B801(CR)
Expand EAN-8 to EAN-13 — Expands EAN-8 data to the EAN-13 data format.
Selecting this feature also changes the symbology ID to match those required
for EAN-13.
021B00(CR)
Don’t Expand to EAN-13
DEFAULT
Expand to EAN-13
021B01(CR)
