Product Reference Guide 153
Appendix F
Host Commands
Host Commands Supported by RS-232 and USB COM
Interfaces
The scanner responds to the following host commands:
COMMAND ASCII HEX COMMENT
Enable Scanner
E 0x45 “Normal operating mode”
Disable
Scanner
D 0x44
“Illumination disabled and
Green LED Flashing”
Reset Scanner
R 0x52 “Scanner resets and emits a single beep.”
Not On FileIndication
F 0x46
“Illumination disabled, scanner emits 3
beeps. Must send the E command to re-
enable scanner.”
Beep Good Read Tone
B 0x42 Beeps if Good Read Beep is enabled
Force Good Read Tone
{SOH} 0x01 Beeps regardless of beep setting
Identification request
i 0x69
“Scanner transmits information data
string
”a
Health request
h 0x68
“Scanner transmits information data
string”a
Status request
s 0x73
“Scanner transmits information data
string
”a
Cell Phone Mode Enable Host
P<count>C
Where: ASCII HEX
P is an ASCII “P” character
‘P’ 0x50
<count> is the binary value of 0x01
