142 Magellan™ 800i Scanner
USB-OEM, USB Keyboard
Pin 1
10 Position RJ
(Scanner End)
, USB COM & USB TEC
External Read Indicator (ERI)
NOTE
This feature is available only thro
ugh use of a special
cable.
1D+
2 
3D-
4 
5
6 
7
8VBUS_VIN
9GND
10
1 
2 
3 
4 
5
6 
7E
RI_OUT
8 VCC_IN (5V ONLY)
9GND
10
