Datalogic Magellan 800i Product Reference Guide

Enter/Exit Programming Mode Interface Features
38 Magellan™ 800i Scanner
Retry on ACK NAK Timeout
Specifies the action the scanner performs after the configurable ACK NAK Tim-
eout Value (set in the following feature) has expired.
032100(CR)
Disable Retry on ACK NAK Timeout
(Transmission failure occurs)
Enable Retry on ACK NAK Timeout
DEFAULT
032101(CR)
ACK NAK Timeout Value
This item specifies the time the scanner will wait for an ACK character from the host following a label transmission. 
00 = Infinite timeout 
01 - 75 = Timeout in 200-millisecond increments 
To configure this feature, scan the ’Enter/Exit Programming Mode’ bar code above to place the unit in Programming
Mode, then the “Set ACK NAK Timeout Value ’Enter/Exit Programming Mode’,” followed by the two digits (zero padded)
from the Alphanumeric table in
Appendix C, Alphanumeric Pad representing your desired value. Exit programming
mode by again scanning the ’Enter/Exit Programming Mode’ bar code
above.
DEFAULT SETTING FOR THIS FEATURE: 01 (200 msec)
0606(CR)
Set ACK NAK Timeout Value
ACK NAK Retry Count
This feature sets the number of times for the scanner to retry a label transmission under a retry condition. 
000 = No retry 
001 - 254 = Retry for the specified number of times 
255 = Retry forever 
To configure this feature, scan the ’Enter/Exit Programming Mode’ bar code above to place the unit in Programming
Mode, then the “Set ACK NAK Retry Count,” followed by the three digits (zero padded) from the Alphanumeric table in
Appendix C, Alphanumeric Pad representing your desired retry count. Exit programming mode by again scanning the
’Enter/Exit Programming Mode’ bar code above
DEFAULT SETTING FOR THIS FEATURE: 003
0608(CR)
Set ACK NAK Timeout Value

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
