94 Magellan™ 9300i / 9400i Scanners
Bar Code Mask
Cut a hole in this page and remove it from the manual as indicated to create a
sleeve through which bar codes (starting in the following section) can be indi
-
vidually viewed and scanned. It is important that only one bar code at a time be
presented to the scanner.
1. Bar Code Mask Sheet 3. Manual (folded)
2. Bar Code
1
2
3

Table of Contents

Other manuals for Datalogic Magellan 9400i

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic Magellan 9400i and is the answer not in the manual?

Datalogic Magellan 9400i Specifications

General IconGeneral
Standard interfacesUSB
Connectivity technologyWired
TypeBuilt-in bar code reader
Sensor typeLinear
Scanner type1D/2D
Light levels (direct sunlight)0 - 86080 lx
Linear (1D) barcodes supportedGS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supportedAztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage100 - 240 V
Input frequency50 - 60 Hz
Power source typeAC
Power consumption (standby)11 W
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Product colorBlack, Grey
Housing material-
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Depth102 mm
Width401 mm
Height130 mm
Weight- g
