Enter/Exit Programming Mode Interface Related Features
240 Magellan™ 9300i / 9400i Scanners
RS-232 ACK NAK Retry Count
This feature sets the number of times for the scanner to retry a label transmis-
sion under a retry condition.
To set the RS-232 ACK NAK Retry Count:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code, Set RS-232 ACK NAK Retry Count on page 240 below.
You’ll need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired number. The selectable range is 000-255
resets. Pad all single and double digit numbers with leading zeroes to yield
a three-digit entry (000-255).
4. The scanner will automatically exit Programming Mode when the appro-
priate amount of digits have been scanned.
NOTE
A setting of 255 specifies “retry forever.”
Set RS-232 ACK NAK Retry Count
Default setting for this feature is:
003 - Three retrys
0608(CR)
DEFAULT

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
