Datalogic Magellan 9400i User Manual

Controls and Indicators
Product Reference Guide 455
Calibration Switch
This switch initiates the scale’s calibration routine. A certified weight set is
needed to perform the scale calibration steps detailed in
Chapter 6, Calibration
Procedures. This switch is not included in scanners without scale modules.
Calibration Switch Seal
This seal allows you to secure the Calibration Switch access cover and restrict
access to the Calibration Switch. If the calibration seal is broken or missing, you
may be prohibited from operating the scale without recertification. Check local
and state requirements for specific restrictions.
Calibration Switch Cover
This cover restricts access to the Calibration Switch to help guard against unau-
thorized tampering when sealed. See Figure 52.
Figure 52. Calibration Switch Cover
LEGAL NOTE
There are regulations that must be followed in order to
ensure compliance when operating a weighing device such as
the scanner/scale. Failure to observe and comply with these
regulations could result in legal action.
LEGAL NOTE
3
1
2
1
Calibration Seal Location
3
Calibration Switch Opening. Use a long,
blunt object to reach in and press the
Calibration Switch.
2
Calibration Access Cover

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
