Datalogic Magellan 9400i User Manual

Scale Features Enter/Exit Programming Mode
Product Reference Guide 157
Scale Sentry Visual Indicator
Sets the Red, Green, Blue values for the Scale Sentry visual indicator.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set Color Scale Sentry Visual Indicator on page 157
below. You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend to
scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired Scale Sentry Visual Indicator Color as listed
below:
- DISABLED = 000000
- RED = 800000
- GREEN = 008000
- BLUE = 000080
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
Set Color Scale Sentry Visual Indicator
Default setting for this feature = 000080 (BLUE)
04C2(CR)
DEFAULT

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
