Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode
Product Reference Guide 253
Single Cable RS-232 Datalogic Extensions
When Datalogic extensions are enabled, scale calibration mode information is
communicated to the host. Contact Customer Support for the format of this
information. Choices for this feature are:
• Standard Protocol
• Support Datalogic Extensions to Protocol
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan your selection from the bar codes below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
Single Cable RS-232 Datalogic Extensions = Standard Proto-
col
Single Cable RS-232 Datalogic Extensions = Support Datalogic
Extensions to Protocol
DEFAULT
050A00(CR)
050A01(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
