82 Magellan™ 9300i / 9400i Scanners
Shift Test (6 Pounds Dual Interval ONLY)
The Shift Test checks to ensure that items placed anywhere on the weighing
surface of the scanner/scale are weighed properly. Refer to
Figure 47 when
performing this test.
Figure 47. Shift Test
DUAL INTERVAL
1. Place and remove, in succession, a six-
pound load on the center of each of the
four quadrants: 1, 2, 3, and 4, (as shown
in
Figure 47) of the scanner/scale’s
weigh platter. Verify that a reading of
between 5.995 and 6.005 lb. registers,
under load, in each quadrant tested.
Check that the display returns to 0.00
between each load.
2. After verifying the accuracy of each
quadrant of the weighing surface,
remove all weight from the scale. This
completes the 6 pound Shift Test.
(Models vary)
2
1
4
3
1
2
3
4

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
