Datalogic Magellan 9400i User Manual

Product Reference Guide 61
Chapter 4
Image Capture and Customer Service Scanner
The scanner provides an image capture function, and can optionally include a
Customer Service Scanner (CSS) for customer convenience. These premium fea
-
tures offer state-of-the-art functionality to point of sale transactions.
Image Capture Feature
In addition to scanning bar codes, the scanner can optionally be used to photo-
graph images presented to the right side of the vertical window
1
. The sales
associate presses the scanner’s Image Capture/CSS button (see Figure 34) to
initiate Image Capture and take pictures.
Pictures can be optionally saved to an archive drive or other device via a cable
connection to the USB ‘B’ Image port (see
Figure 3).
Figure 34. Image Capture
1. This feature can optionally be configured to capture images through the horizontal window
instead. See the
Imaging and CSS Features on page 103 section for more details.
NOTE
The way in which the scanner takes pictures in Image Capture Mode
is a configurable feature. See
Chapter 7, Programming for more
details.

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
