Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode General Scanner and Scale Features
168 Magellan™ 9300i / 9400i Scanners
Scale Baud Rate
This feature sets the RS-232 scale baud rate setting for scale interfaces that
have adjustable baud rate. The options are:
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan your selection from the bar codes below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
•default
• 1200 baud
• 2400 baud
• 4800 baud
• 9600 baud
• 19200 baud
• 38400 baud
• 57600 baud
• 115200 baud
• 230400 baud
• 460800 baud
• 912600 baud
Scale Baud Rate = default
Scale Baud Rate = 1200
Scale Baud Rate = 2400
Scale Baud Rate = 4800
DEFAULT
041300(CR)
041301(CR)
041302(CR)
041303(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
