Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode Data Editing
272 Magellan™ 9300i / 9400i Scanners
Label ID
Label ID Control
This feature specifies whether or not Label IDs are transmitted to the host and
if so, whether to attach them as a prefix or suffix.
Choices are:
•Disable
• Enable as a Prefix
• Enable as a Suffix
To select the option for Label ID Control:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the desired option from the bar codes below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
Label ID Control = Disable
Label ID Control = Enable as a Prefix
Label ID Control = Enable as a Suffix
020500(CR)
020501(CR)
DEFAULT
020502(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
