Datalogic Magellan 9400i User Manual

464 Magellan™ 9300i / 9400i Scanners
4. Carefully insert the microSD card into the slot until it "clicks" into place.
Figure 54. Inserting the MicroSD Card
5. If installed properly, you should immediately hear an audible signal upon
insertion or removal of a microSD card. Various operations will also be
indicated by the scanner’s good read LED.
microSD Card Removal
Push in gently using your finger or thumbnail to disengage and remove the
microSD card. Remember to keep your finger in place atop the card’s edge to
avoid accidentally “launching” the card from the spring-loaded slot.
CAUTION
The microSD card slot is spring-loaded. Keep your finger lightly in place atop
the card until you are sure it is fully seated in place. See
Figure 54
Use your finger or thumbnail to push in on the top edge of the card to be
slightly below flush with the scanner enclosure when inserting or removing
the card. This will engage/disengage the spring mechanism.
Never insert tools or other foreign objects into the microSD card slot.
microSD Card
Scanner
Push down
past flush to
seat, then
carefully
release.
Seated card

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
