84 Magellan™ 9300i / 9400i Scanners
Increasing- Load Test (Single Interval Phase 2) (Dual Interval Phase 3)
After completing the Shift Test, you must complete the Increasing Load Test
using 20.0, 25.0 and 30.0 pounds of weight.
Blanking Test
This test ensures that the scanner/scale will indicate its weighing capability has
been exceeded if a weight greater than 0.05 pounds over its maximum upper
weight is placed upon the unit.
1. Place weights that total the upper weight limit plus 0.051 pounds on the
scale. For example: If the upper limit is set at 30 pounds, place weights
totaling 30.051 pounds on the scale.
2. Verify that the display shows a dash and three hyphens (_ - - -). This is the
overweight indication.
NOTE
The upper limit of the scale is configurable according to the
POS interface type and may not necessarily be set at 30
pounds, which is the standard setting. For this test, continue to
place weights in five pound increments only up to the upper
weight limit set for your scale.
SINGLE INTERVAL DUAL INTERVAL
After completing the Shift Test, you must
complete the Increasing Load Test using
20.0, 25.0 and 30.0 pounds of weight.
After completing the Shift Test, you must
complete the Increasing Load Test using 8.0,
10.0 and 12.0 pounds of weight.
1. With the scale starting at zero, place
20.0 pounds in the center of the weigh
-
ing surface and check that the display
reads between 19.99 and 20.01 lb.
1. With the scale starting at zero, place 20.0
pounds in the center of the weighing
surface and check that the display reads
between 19.99 and 20.01 lb.
2. Place an additional five pounds in the
center of the weighing surface, increas
-
ing the load to 25.0 pounds and check
that the display reads between 24.99
and 25.01 lb.
2. Place an additional five pounds (25 pounds
total) in the center of the weighing surface.
Check that the display reads between 24.99
and 25.01 lb.
3. Place an additional five pounds in the
center of the weighing surface increas
-
ing the load to 30.0 pounds and check
that the display reads between 29.99
and 30.01 lb.
3. Place an additional five pounds in the
center of the weighing surface increasing
the load to 30.0 pounds and check that the
display reads between 29.99 and 30.01 lb.
4. Remove the weights and verify that the
display reads 0.00.
4. Remove the weights and verify that the
display reads 0.00.
5. You have completed the Increasing-
Load Test (Phase 2)
5. You have completed the Increasing-Load
Test (Phase 3).
NOTE
The scanner/scale may blank (show an underscore and three
hyphens) at any weight greater than its upper weight limit, but
must blank when the upper weight limit plus 0.051 pounds are
set upon the weighing surface.

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
