Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode Interface Related Features
230 Magellan™ 9300i / 9400i Scanners
RS-232 TTL
Specifies whether RS-232 interface provides TTL levels on the output pins TxD
and RTS.
Choices are:
• Normal RS-232 levels
• TTL levels
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below which represents the desired setting for this fea-
ture. You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend to
scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
RS-232 TTL = Normal RS-232 levels
RS-232 TTL = TTL Levels
DEFAULT
028500(CR)
028501(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
