Datalogic Magellan 9400i User Manual

Product Reference Guide 463
Appendix D
MicroSD Card
MicroSDHC Compatibility
Currently, the microSD card interface for this product supports SD-Memory
Card Specifications/ Part 1. Physical Layer Specification; Version 1.01, but the
processor MCI can communicate with SDHC Cards. For example, the scanner
can perform the functions specified in this appendix for the SDA 2.0 specifica
-
tion. Both FAT16 and FAT32 formats are supported.
Filenames are limited to the 8.3 file naming format (i.e., FILENAME.EXT), and
MUST be capitalized.
MicroSD Card Insertion
1. Read all of these instructions before starting.
2. Apply power to the scanner.
3. Lift the rubber cover to access the card slot as shown in Figure 53.
Figure 53. SD Card Location
1
2
3
1
microSD Card Slot
2
Rubber Cover
3
microUSB Port

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
