Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode
Product Reference Guide 213
IBM Scale Address
Specifies IBM scale address for IBM Port 17. The following three addresses are
available:
•6A
•6B
•6E
To set the IBM Scale Address:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code below that represents the desired scale address desig-
nation.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
NOTE
This feature applies to IBM Port
17 ONLY.
IBM Scale Address = 6A
IBM Scale Address = 6b
IBM Scale Address = 6E
04156A(CR)
04156B(CR)
DEFAULT
04156E(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
