Enter/Exit Programming Mode Imaging and CSS Features
106 Magellan™ 9300i / 9400i Scanners
Image Capture to the Host by Camera Button
Perform the following steps to set up the Camera Button.
1. Set the Camera Button feature to enabled
2. Set the Image Capture destination to host port
3. Press the camera button
Scanner will beep for a few seconds, then take picture and send the Image
Retrieval Event label to the POS to indicate image is ready. The data content of
the event label is:
A856102000239
The POS sends the picture retrieval command to initiate picture download from
the scanner. Format of the command is:
P\x02pG
The scanner sends the picture to the POS with the transmission format
described in the previous section, “Image Capture By Host Command”.
Camera Button Mode
This feature enables or disables the camera button.
Camera Button Mode = Disabled
Camera Button Mode = Enable
DEFAULT
05B000(CR)
05B001(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
