Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode
Product Reference Guide 359
Code 39 Length 2
If Code 39 Length Control is set to Fixed-Length decoding, this feature speci-
fies Code 39 second fixed length. If Code 39 Length Control is set to Variable-
Length decoding, this feature specifies the maximum label length.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set Code 39 Length 2 on page 359 below. You’ll need
to cover any unused bar codes on this and the facing page to ensure that
the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired label length. The selectable range for this
option is 00, no second fixed length, or 01 to 50. Pad all single digit num
-
bers with a leading zero to yield a two-digit entry (00-50).
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
NOTE
When in Fixed Length mode, if Length 2 is set to the value
of 00, then only Length 1 will apply
Set Code 39 Length 2
Default setting for this feature = 32 (length = 50)
04B3(CR)
DEFAULT

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
