Enter/Exit Programming Mode
Product Reference Guide 267
these settings) across all symbologies (set via the Global features in this
chapter).
• You can add any character from the ASCII Character Set on page 507 (from
00-7F) on the inside back cover of this manual as a prefix, suffix or Label
ID.
• Enter prefixes and suffixes in the order in which you want them to appear
on the output.
Case Conversion
This option can change the case of all alphabetic characters to upper or lower
case.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan bar code for the desired option below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
Case Conversion = No Case Conversion
Case Conversion = Upper Case
Case Conversion = Lower Case
DEFAULT
033100(CR)
033101(CR)
033102(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
