Enter/Exit Programming Mode Imaging and CSS Features
122 Magellan™ 9300i / 9400i Scanners
CSS Features
The Customer Service Scanner (CSS) is an optional scanning unit with which
your scanner may be equipped. The following options are available for the CSS:
Image Capture / CSS Button
The scanner’s Image Capture/CSS button can be programmed for use by the
sales associate to activate or deactivate the CSS using that button. This allows
the associate to control when customers are able to scan bar codes in the fol
-
lowing manner:
CSS Button Option Enabled — Depending upon its current state, the CSS function
can be turned OFF or ON by a momentary press of the CSS button.
CSS Button Option Disabled — When this feature is disabled, a connected CSS is
always ON, and is not effected by a push of the Image Capture/CSS button.
NOTE
The CSS will be turned ON automatically on power up.
CSS Button Option = Disable
CSS Button Option = Enable
DEFAULT
05B100(CR)
05B101(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
