32 Magellan™ 9300i / 9400i Scanners
SECTION III. INSTALLATION
Overview
The preceding Site Requirements on page 20 dealt with installed location and
counter preparations to accommodate the scanner or scanner-scale. Having
completed those steps, physical installation of the scanner or scanner-scale
can begin. The following instructions apply to all models.
These setup and installation procedures assume that you have already prepared
your checkstand to receive the scanner or scanner-scale. If you have not
already made the counter cutout, do so now as described in the previous
instructions. If your checkstand has been prepared, proceed as follows:
1. Unpack the unit.
2. Route & Connect Cables.
3. Powerup & Operational Verification.
4. Connect to POS system, re-test to verify operation when connected to the
POS system.
5. Install unit in counter.
1. Unpack
To unpack the unit:
• Inspect the package for signs of damage that may have occurred during
shipping. If damage is found, report it to your carrier immediately.
• Lift out the accessory box containing the AC/DC Power Supply, optional
Remote Scale Display and cable (if present), and the Quick Reference
Guide.
• Remove the Quick Reference Guide and familiarize yourself with the unit’s
controls and features. Leave the guide at the checkstand when the instal
-
lation is complete.
• Remove the protective packing and carefully lift the unit from the carton.
B e sure to save the box and all packing material. In the event of failure, the
unit must be returned to the factory in its original packaging.
• Carefully lift off the All Weighs™ Platter as shown in Figure 23 and remove
the protective foam pieces securing the weigh mechanism. Set the platter
back in place.
NOTE
For added protection during shipment, the AllWeighs™ Platter is
covered with a tight-fitting layer of vinyl as shown in
Figure 16.
This vinyl layer MUST BE REMOVED before placing the unit into ser-
vice.
If the unit is equipped with a scale, the scale spacer (below the plat-
ter) must also be removed prior to use.

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
