Enter/Exit Programming Mode 1D Symbology Programming
348 Magellan™ 9300i / 9400i Scanners
DataBar Expanded Length 2
Length 2 is the maximum label length if in variable length mode, or the second
fixed length if in fixed length mode. Length includes the bar code's data char
-
acters only.
To set this feature:
1. Scan the ENTER/EXIT Programming Mode bar code.
2. Scan the bar code, Set DataBar Expanded Length 2 on page 348 below.
You’ll need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired label length. The selectable range for this
option is 00 to 74. Pad all single digit numbers with a leading zero to yield
a two-digit entry (00-74).
4. Complete the programming sequence by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
NOTE
When in Fixed Length mode, if Length 2 is set to the value
of 00 (zero), then only Length 1 will apply.
Set DataBar Expanded Length 2
Default setting for this feature = 4A (length = 74)
04BF(CR)
DEFAULT
