Datalogic Magellan 9400i User Manual

Enter/Exit Programming Mode Interface Related Features
262 Magellan™ 9300i / 9400i Scanners
Keyboard Wedge Quiet Interval
This setting specifies the amount of time to monitor for keyboard activity
before breaking the keyboard connection.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code, Keyboard Wedge Quiet Interval on page 262. You’ll
need to cover any unused bar codes on this and the facing page to ensure
that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the desired time interval. The selectable range is 001-100,
which is the interval in 10-millisecond increments. Pad all single and dou
-
ble digit numbers with leading zeroes to yield a three-digit entry (001-
100).
Examples:
001 = 10ms
005 = 50ms
040 = 400ms
100 = 1,000ms (1 second)
4. The scanner will automatically exit Programming Mode when the appro-
priate amount of digits have been scanned.
Set Keyboard Wedge Quiet Interval
Default setting for this feature is:
00A - 100ms
0303(CR)
DEFAULT

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
