Enter/Exit Programming Mode Interface Related Features
212 Magellan™ 9300i / 9400i Scanners
IBM Features
IBM Interface Options
IBM interfaces offer specific control over interaction with certain devices.
Options for this feature are as follows:
• FULL host interface support — Accepts scanner and scale configuration
host commands.
• Ignore host interface configuration of scanner and scale — Ignores all
scanner and scale configuration host commands.
To set this feature:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan your selection from the bar codes below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the scanner
reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit Pro-
gramming Mode bar code.
NOTE
The USB OEM interface provides its own set of
options. Refer to the feature, USB OEM Interface
Options, in this section.
IBM Interface Option = Full Host Interface Support
IBM Interface Option = Ignore Host I/F Config of Scanner &
Scale
DEFAULT
055000(CR)
055006(CR)

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
