Datalogic Magellan 9400i User Manual

Product Reference Guide i
Table of Contents
Chapter 1. INTRODUCTION.......................................................................................................................................................................1
Manual Overview .............................................................................................................................................................................. 1
How to Use This Manual .......................................................................................................................................................... 2
Scanner Features .............................................................................................................................................................................. 3
Connectors and Ports .............................................................................................................................................................. 4
To Checkpoint® or Nedap® EAS System ......................................................................................................................................... 4
To Sensormatic® EAS System ......................................................................................................................................................... 4
Physical Parameters ........................................................................................................................................................................ 6
Scanning .................................................................................................................................................................................... 6
EAS Tag Deactivation System ................................................................................................................................................. 6
Weighing .................................................................................................................................................................................... 7
Scale Sentry
TM
Option ............................................................................................................................................................. 7
Warm-Up Time ......................................................................................................................................................................... 8
Electrical Specifications ................................................................................................................................................................... 9
Power Supply ............................................................................................................................................................................ 9
Safety Precautions ................................................................................................................................................................. 10
Labeling ........................................................................................................................................................................................... 11
Agency Compliances ...................................................................................................................................................................... 12
Bar Codes Supported ...................................................................................................................................................................... 14
1D Symbologies ...................................................................................................................................................................... 14
2D Symbologies ...................................................................................................................................................................... 14
References ....................................................................................................................................................................................... 14
Technical Support ........................................................................................................................................................................... 15
Datalogic Website Support .................................................................................................................................................... 15
Reseller Technical Support .................................................................................................................................................... 15
Telephone Technical Support ................................................................................................................................................ 15
Chapter 2. SITE PREPARATION AND INSTALLATION...........................................................................................................................17
SECTION I. Pre-Installation Considerations ................................................................................................................................ 17
Ergonomic Recommendations ...................................................................................................................................................... 18
Checkstand Design ................................................................................................................................................................. 19
Site Requirements .................................................................................................................................................................. 20
Scanner Dimensions ............................................................................................................................................................. 25
SECTION II. Checkstand Preparation ............................................................................................................................................ 27
Counter Cutout ........................................................................................................................................................................ 27
SECTION III. Installation ................................................................................................................................................................. 32
Overview .................................................................................................................................................................................. 32
Optional Remote Scale Display ..................................................................................................................................................... 45
Placement/Installation .......................................................................................................................................................... 45
Chapter 3. OPERATION AND MAINTENANCE.......................................................................................................................................49
Scanning Items ............................................................................................................................................................................... 49
Proper Weighing Technique (Scale Models) ......................................................................................................................... 50
Deactivating Security Labels ................................................................................................................................................. 51
Operational Controls ...................................................................................................................................................................... 53
Operational Modes ......................................................................................................................................................................... 53

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
