Enter/Exit Programming Mode Interface Related Features
236 Magellan™ 9300i / 9400i Scanners
RS-232 ACK Character
This feature specifies which ASCII character will be used as an ACK character.
To specify the RS-232 ACK Character:
1. Scan the Enter/Exit Programming Mode bar code.
2. Scan the bar code, SET RS-232 ACK Character below. You’ll need to cover
any unused bar codes on this and the facing page to ensure the scanner
reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Keypad on page 461 in Appendix C
that represent the hex designation for the desired character. A table con-
taining the ASCII Character Set and their corresponding Hex Values is
available in the inside back cover of this manual. ASCII parameters must be
input by scanning a pair of hexadecimal digits for the desired character.
For example, if ASCII “A” were the desired ACK character, you would scan
the digits “4”, then “1” (the ASCII corresponding hex value).
4. The scanner will automatically exit Programming Mode when the appro-
priate amount of digits/characters have been scanned.
NOTE
DO NOT set this feature to use previously defined char-
acters such as XON, XOFF or host commands as this will
conflict with normal operation of these characters. 8-bit
data is not recognized when the feature, RS-232 Num
-
ber of Data Bits, is set to 7 data bits.
Set RS-232 ACK Character
Default setting for this feature is:
06 - ACK
031F(CR)
DEFAULT

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
