About this Manual
Product Reference Guide
3
About this Manual
This Product Reference Guide (PRG) is provided for users seeking advanced
technical information, including connection, programming, maintenance and
specifications. The Quick Reference Guide (QRG) and other publications associ-
ated with this product are downloadable free of charge from the website listed
on
the back cover of this manual.
Typically, units are factory-programmed for the most common terminal and
c
ommunications settings. If you need to modify any programmable settings,
custom configuration can be accomplished by scanning the programming bar
codes within this guide.
Programming can alternatively be perfor
med using the Datalogic Aladdin™
Configuration application, which is available from the Datalogic website listed
on the back cover of this manual. This multi-platform utility program allows
device configuration using a PC. It communicates to the device using a serial or
USB cable and can also create configuration bar codes to print.
Overview
Chapter 1, Introduction
provides a product overview, unpacking instructions, and
cable connection information.
Chapter 2, Setup
presents information about unpacking and setting up the scan-
ner, and interface configuration
bar codes and details.
Chapter 3, Configuration Using Bar Codes
provides instructions and bar code labels
for customizing your scanner. There are different sections for interface types,
gen
eral features, data formatting, and symbology-specific features.
Chapter 4, References
provides details concerning programmable features.
Appendix A, Technical Specifications
lists physical and performance characteristics,
as well as environmental and regulatory specifications. It also provides stan-
dard cable pin-outs and descri
ptions of the functions and behaviors of the
scanner’s LED and Speaker indicators.
Appendix B, Standard Defaults
references common factory default settings for
scanner features and options.
Appendix C, Sample Bar Codes
offers sample bar codes of several common sym-
bologies.
Appendix D, Keypad
includes numeric bar codes to be scanned for certain
parameter settings.
Appendix E, Scancode Tables
lists control character emulation information for
Wedge and USB Keyboard interfaces.
Manual Conventions
The symbols listed below are used in this manual to notify the reader of key
issues or procedures that must be observed when using the scanner:
NOTE
Notes contain information necessary for
properly diagnosing, repairing
and operating the scanner.
