1D Symbologies Enter/Exit Programming Mode
Product Reference Guide 177
ISBT 128 Force Concatenation
When enabled, this feature forces all ISBT 128 labels to be concatenated.
NOTE
DEFAULT
ISBT 128 Force Concatenation = Disable
ISBT 128 Force Concatenation = Enable
This option is only valid when ISBT 128 Concatenation on
page 175 is enabled. (see page <Links>9-175).
ISBT 128 Advanced Concatenation Options
NOTE
Use the Datalogic Aladdin configuration application or Contact Customer Support to
set up pairs of label types for concatenation.
$CI8FC00
$CI8FC01

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
