Datalogic RIDA DBT6400 User Manual

Product Reference Guide i
Table of Contents
INTRODUCTION ....................................................................................................................................................... 1
About the Scanner .............................................................................................................................................................1
Using the RIDA DBT6400 ..........................................................................................................................................1
About this Manual .............................................................................................................................................................3
Overview ....................................................................................................................................................................3
Manual Conventions .................................................................................................................................................3
Technical Support ..............................................................................................................................................................4
Datalogic Website Support ......................................................................................................................................4
Reseller Technical Support ......................................................................................................................................4
Telephone Technical Support ..................................................................................................................................4
SETUP....................................................................................................................................................................... 5
Unpacking ...........................................................................................................................................................................5
Setting Up the Reader .......................................................................................................................................................5
Configuring the BC6020 Base Station ....................................................................................................................5
Using the BC6020 Base Station ..............................................................................................................................6
Charging the Batteries .............................................................................................................................................7
Replacing the Battery Pack ......................................................................................................................................8
Linking to a Host ................................................................................................................................................................9
Linking to a Base Station ............................................................................................................................................... 11
Base Station Interface Selection ................................................................................................................................... 12
Configuring the Interface ...................................................................................................................................... 12
Customizing Configuration Settings ............................................................................................................................ 13
Using the Programming Bar Codes ..................................................................................................................... 13
Interface Settings .................................................................................................................................................. 14
Configuring Other Features .................................................................................................................................. 14
Software Version Transmission ........................................................................................................................... 14
Compatibility ................................................................................................................................................................... 16
Supported BT Specification ................................................................................................................................... 16
Device and operative system supported ............................................................................................................. 16
Tested Devices ....................................................................................................................................................... 17
CONFIGURATION USING BAR CODES.................................................................................................................. 19
Configuration Parameters ............................................................................................................................................. 19
Global Interface Features .............................................................................................................................................. 21
Host Commands — Obey/Ignore ........................................................................................................................ 21
USB Suspend Mode ............................................................................................................................................... 22
USB-COM INTERFACES 23
Standard Factory Settings ............................................................................................................................................. 23
Intercharacter Delay ....................................................................................................................................................... 24
Beep On ASCII BEL .......................................................................................................................................................... 25
Beep On Not on File ........................................................................................................................................................ 25
ACK NAK Options ............................................................................................................................................................ 26
ACK Character ......................................................................................................................................................... 27
NAK Character ........................................................................................................................................................ 27
ACK NAK Timeout Value ........................................................................................................................................ 28
ACK NAK Retry Count ............................................................................................................................................ 29
ACK NAK Error Handling ....................................................................................................................................... 30
Indicate Transmission Failure ....................................................................................................................................... 31
Disable Character ............................................................................................................................................................ 31
Enable Character ............................................................................................................................................................. 32
KEYBOARD INTERFACE 33
Country Mode .................................................................................................................................................................. 34
Setup on PC to use ALT Universal ........................................................................................................................ 34

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
