Datalogic RIDA DBT6400 User Manual

Wireless Features Enter/Exit Programming Mode
Product Reference Guide 255
Docking Beep
Enables/disables a beep indication when the handheld is placed in the Base Station.
$CBTCB00(CR)
Docking Beep = Disable
$CBTCB01(CR)
Docking Beep = Enable
DEFAULT
Leash Alarm
This setting specifies the number of seconds to sound the Leash Mode beeps (three
per second) when the handheld goes out of range. This is especially useful in instances
where the reader might inadvertently have been placed in a bag or cart.
For this mode to be effective, the reader must be linked to the Base Station or to the
Ho
st. If the reader is asleep or disconnected from the Base Station, there is no way for
it to know where it is relative to the Base Station because communication is not active
between the devices.
DEFAULT
$CBTLB00(CR)
Leash Alarm = Disabled
$CBTLB01(CR)
Leash Alarm = 1 Second
$CBTLB02(CR)
Leash Alarm = 2 Seconds

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
