Enter/Exit Programming Mode Data Matrix
204 RIDA™ DBT6400
Data Matrix Set Length 2
This feature specifies one of the bar code lengths for Data Matrix Length Con-
trol on page 203. Length 2 is the maximum label length if in Variable Length
Mode, or the second fixed length
if in Fixed Length Mode. Characters can be set
from 0001 to 3,116 characters in increments of 0001 (pad with zeroes).
See page 250 for detailed instructions on setting this feature.
Select Data Matrix Length 2 Setting
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code at
left followe
d by the digits from the Alphanumeric char-
acters in
Appendix D, Keypad
representing your
desired character(s). End by scanning the ENTER/E
XIT
bar code again.
Make a mistake? Scan the CANCEL bar code to abort and
not save
the entry string. You can then start again at the
beginning.
CANCEL
Length 2 is 3,116 Characters
To Next Page
