Enter/Exit Programming Mode Datalogic 2 of 5
150 RIDA™ DBT6400
Datalogic 2 of 5 Check Character Transmission
This option enables/disables transmission of an optional Datalogic 2 of 5 char-
acter.
Datalogic 2 of 5 Check Character Transmission = Don’t Send
Datalogic 2 of 5 Check Character Transmission = Send
DEFAULT
Datalogic 2 of 5 Length Control
This feature specifies either variable length decoding or fixed length decoding
for the Datalogic 2 of 5 symbology.
Variable Length: For variable length decoding, a minimum and maximum length
may be set.
Fixed Length: For fixed length decoding, two different lengths may be set.
DEFAULT
Datalogic 2 of 5 Length Control = Variable Length
Datalogic 2 of 5 Length Control = Fixed Length
$CD2CT00
$CD2CT01
$CD2LC00
$CD2LC01

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
