Datalogic RIDA DBT6400 User Manual

Enter/Exit Programming Mode Audio Jingles
82 RIDA™ DBT6400
Audio Jingle Enable
This option determines whether the scanner will sound predefined “Jingles” (a
short, user-defined tune uploaded via Datalogic Aladdin™ configuration soft-
ware) or traditional beep sounds to
indicate good read.
See below for parameters to define which preloaded
Jingle to sound upon
power-up or good read events. Additional items such as enter stand mode, exit
stand mode, and error beep can also be programmed using Datalogic Aladdin.
DEFAULT
Audio Jingle = Disable (Use traditional beep sounds)
Audio Jingle = Enable Jingles
$CAUEN00
$CAUEN01

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
