Datalogic RIDA DBT6400 User Manual

Product Reference Guide 271
Appendix A
Technical Specifications
The table below contains Physical and Performance Characteristics, User Envi-
ronment and Regulatory information.
Table 19. Technical Specifications
Item Description
Electrical Features
Battery Type Li-Ion battery pack.
Typical charge time for full
charge from
auto power off
2,5 hours when placed on Based Station or when Host pow-
ered through the micro USB cable connection
a
a.
Charge times are much lower when battery is within daily typical operating condition.
.
Operating autonomy

(continuous reading)
4000 readings or 5 hour connected to
a Host. (with aggressive
power saving profile).
Max. Scan Rate 60 frames/sec.
Reading Indicators
Side and Top Illumination, Good R
ead Spot, Beep, Jingle or
Viber.
Cradle Consumption and DC
in
put supply range
5V +/- 10%; Power < 8W (b); Max 500mA when in host/bus

powered mode
b
b.
Typical input current measured under factory default configuration.
.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
