Datalogic RIDA DBT6400 User Manual

Wireless Features Enter/Exit Programming Mode
Product Reference Guide 265
OTHER BT FEATURES
Bluetooth HID Alt Mode
Enable/Disable the ability to correctly transmit a label to the host regardless of
the Bluetooth HID Country Mode selected, when Bluetooth HID Profile is config-
ured.
Read the configuration command label be
low for the HID Alt Mode feature.
HID Alt Mode = OFF
DEFAULT
DEFAULT
HID Alt Mode = ON
Bluetooth HID Send Unknown ASCII Char
Unknown characters are characters the host does not recognize. When Disable
HID Send ASCII Unknown character is selected, all barcode data is sent except
for unknown characters, and an error beep will sound. When HID Send Unknown
ASCII character is enabled, an unknown character will be sent as a SPACE.
DEFAULT
$CBTHO00(CR
HID Send Unknown ASCII character = Disable
CBTHO01(CR
HID Send Unknown ASCII character = Enable

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
