LED and Beeper Indications
Product Reference Guide
275
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate various func-
tions or errors on the reader. An optional “Green Spot” also performs useful
fu
nctions. The following tables list these indications. One exception to the
behaviors listed in the tables is that the reader’s functions are programmable,
and so may or may not be turned on. For example, certain indications such as
the power-up beep can be disabled using programming bar code labels.
Table 20. LED and Speaker Indications
Indication Description LED Beeper
Power-up Beep
The reader is in the process
of po
wering-up.
Fast RGB loop for Top Led.
Reader beeps four times
at
highest frequency and
volume upon power-up.
Good Read Beep
A label has been successfully
scanned
by the reader.
LED behavior for this indi-
cation is configurable via
the feature “Good Read:
When to Indicate”.
The reader will beep once
at
current frequency, vol-
ume, mono/bi-tonal set-
ting and duration upon a
suc
cessful label scan.
ROM Failure
There is an error in the
reader'
s software/program-
ming.
Top Led Flashes.
Reader sounds one error
beep at highest
volume.
Limited Scanning
Label Read
Indicates that a Host con-
nection is not established
w
hen the USB interface is
enabled.
N/A
Reader 'chirps' six times
at the highes
t frequency
and current volume.
Reader Active Mode
The reader is active and
ready to
scan.
Side LED is lit steadily
a
a.
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected.
.
N/A
Reader Disabled
The reader has been disabled
by the
Host.
Top LED blinks continu-
ously.
N/A
Green Spot
a
flashes
momentarily
Upon successful read of a
labe
l, the software shall turn
the green spot on for the
time specified by the config-
ured value.
Upon successful read of a
label, the software shall
turn the green spot on for
the time specified by the
configured value.
N/A
