Datalogic RIDA DBT6400 User Manual

1D Symbologies Enter/Exit Programming Mode
Product Reference Guide 175
ISBT 128
The following options apply to the ISBT 128 symbology.
ISBT 128 Concatenation
Enables/disables ISBT128 concatenation of 2 labels.
DEFAULT
ISBN 128 Concatenation = Disable
ISBN 128 Concatenation = Enable
ISBT 128 Concatenation Mode
Specifies the concatenation mode between Static and Dynamic.
DEFAULT
ISBT 128 Concatenation Mode = Static
ISBT 128 Concatenation Mode = Dynamic
$CI8CE00
$CI8CE01
NOTE
This option is only valid when
ISBT 128 Concatenation on page 175 is enabled
(see page <Links>9-175).
$CI8CM00
$CI8CM01

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
