Serial Parameters
Product Reference Guide
227
• Enable for label transmission — The scanner expects an ACK/NAK
response from the host when a label is sent
• Enable for host-command acknowledge — The scanner will respond with
ACK/NAK when the host send
s a command
• Enable for label transmission an
d host-command acknowledge
ACK Character
This setting specifies an ASCII character or hex value to be used as the ACK
character. ASCII characters or any hex value from 0 to 0xFF can be selected.
NOTE
Setting to previously defined characters such as XON, XOFF, or host com-
mands conflicts with normal operation of these characters.
1. Determine the desired character or value.
2. Use the
ASCII Chart on page 303
on the inside back cover of this manual to
find the hex equivalent for the desired character/value.
3. Go to
page 27
and scan ENTER/EXIT PROGRAMMING MODE to enter Pro-
gramming Mode.
4. Scan the bar code: SELECT ACK CHAR
ACTER SETTING.
5. Scan the appropriate two alphanumeric characters from the keypad in
Appendix D, Keypad
, that represent the desired character/value determined
above. The second character will cause a two-beep indication.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit.
See the table below for examples of how to set this feature.
Table 3. ACK Character Setting Examples
STEP ACTION EXAMPLES
1 Desired Character/Value
ACK $ @ >
2
Hex equivalent from
ASCII
Chart on page 303
0x06 0x24 0x40 0x3E
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT ACK CHARACTER SETTING
5
Scan Two Characters from
Appendix D, Keypad
‘0’ and ‘6’ ‘2’ and ‘4’ ‘4’ and ‘0’ ‘3’ AND ‘E’
6 Scan ENTER/EXIT PROGRAMMING MODE
NAK Character
This setting specifies an ASCII character or hex value to be used as the NAK
character. ASCII characters or any hex value from 0 to 0xFF can be selected.
To Next Page
