Data Format
Product Reference Guide
241
Label ID: Set Individually Per Symbology — continued
Table 12
STEP ACTION EXAMPLES
1.
Scan the ENTER/EXIT bar
code
(Scanner enters Programming Mode)
2.
Determine placement of the
Label ID characters BEFORE
or AFTER w
ith regard to
scanned data using
"Label
ID Control"
on page 69
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting
the symbology type you
wish to designate label ID
characters for
using
Label ID
Symbology
Selection, starting on page
70
.
GS1 DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from
the ASCII table (inside
back
cover), then scan in these
digits/characters using the
bar codes in the section:
Keypad, starting on page
295
. f you make a mistake
before the last character,
scan the CANCEL bar code
to abort and not save the
entry string. You can then
start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6.
Scan the ENTER/EXIT bar
code
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar
code once again
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
. Label ID Examples
To Next Page
