Datalogic RIDA DBT6400 User Manual

Item Description
Environmental Features
Working Temperature 0° C to + 50° C (+32° to +122° F)
Storage Temperature -20° C to + 70° C (-4° to +158° F)
Charging Temperature 0° C to + 40° C (32° to +104° F)
Humidity 90% non condensing
Drop Resistance
IEC 68-2-32 Test ED
Scanner: 1.5 m (4.9 ft)
Base Station: 0.9 m (3 ft)
ESD Protection 16 KV for the reader
Protection Class
Scanner: IP50
Base Station: IP40
Weight (without cable)
Scanner: approx. 150g (5.3 oz)
Base Station: approx. 103g (3.6 oz)
Size
Scanner: approx 110 x 43 x 35 mm
Base Station: approx. 71 x 70 x 69 mm
Radio Features
Frequency Range 2400 to 2483.5 MHz
Range (in open air) 25 m
Product Reference Guide 273

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
