Delphin ProfiMessage User Manual

ProfiMessage
Thefollowingareexamplesofpossibleusesforthepulsegenerator.
Example 1

Inthisexample,thepulsegeneratorrunsincontinuousmode.Thecycletimeis5
seconds.Achannelhasbeenselectedforthepulsewidththatinitiallyoutputsthe
value1andthenthevalue2.Thechannelisnotpermittedtooutputanegative
value(nonegativetimes)noravaluegreaterthanthecycletime,i.e.5inthis
example.Anotherchannelisgivenforthereset.
105
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
