Delphin ProfiMessage User Manual

ProfiMessage
Operationcanreducethenumberofanalogueinputsfrom8to4/2/1.This
reducesthetimeforevaluationandformeasurementdatatransmission,or
increasesthetriggerrate.Somefunctionsareavailableonlyforsettingsof≤4
channels.ReferalsotothesectionProjectplanning
.
This setting takes priority over the analogue inputs
marked as active.
Sample rate
Setsthesamplingfrequencyinthe256Hzto20480Hzrange.Thesettingis
appliedtoallselectedanalogueinputs.TheOperating modesettingsaffectthe
optionsthatareavailablehere.
Number of samples
Thenumberofsamplesisset(i.e.measurementvalues)inthe128to8192range
foratimesignal.Thesettingisappliedtoallselectedanalogueinputs.TheOper-
ating modesettingsaffecttheoptionsthatareavailablehere.
Recording time
Informationaboutthetimesignal.Itisdeterminedfromthesamplingfrequency
andthenumberofsamplesandthendisplayedhere.
Frequency range/number of lines/frequency resolution
Informationaboutthefrequencyspectrum.Itisdeterminedfromthesamplingfre-
quencyandnumberofsamplesandthendisplayedhere.
Time signal tab
287
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
