ProfiMessage
Trigger threshold
Foranalogueinputtriggering,itsetsthethresholdvalueat±0…100%ofthe
inputmeasuringrange.
Pre-Trigger
Thisoptionisavailableonlyforthebatchoperatingmode.
Fortriggeringviaanalogueordigitalinput,itsetstheamountofsignalpre-history
as0...100%ofrecordingdepth(i.e.signallength).
Mode and polarity
Setsthetypeofresolution.Analogueinput:Over-runorunder-runofthe
threshold/limitvalue.Digitalinput:Forlogical1orlogical0.
Start-stop trigger and number of trigger pulses
Thisoptionisavailableonlyforthebatchoperatingmode.
Thisoptiondynamicallycontrolstherecordingsignallengthforanalogueordigital
inputtriggering.RefertothesectionTriggeringandrecording.
Recording tab

Analogue inputs used
286
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
