TEST ACTION APPLICABILITY
3 Note: Ensure there is PCI bus communication with other modules. If not,
refer to the PCI Bus Communication Failure symptom and repair as
necessary.
WARNING: TO AVOID PERSONAL INJURY OR DEATH, TURN THE IGNI-
TION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BE-
FORE PROCEEDING.
Disconnect the ACM harness connector.
Connect the appropriate Load Tool ACM Adapter to the ACM connector.
Turn the ignition on and then reconnect the Battery.
Use Scope input cable CH7058, Cable to Probe adapter CH7062, and the red and
black test probes.
Connect the scope input cable to the channel one connector on the DRB. Attach the
red and black leads and the cable to probe adapter to the scope input cable.
With the DRBIIIt select Pep Module Tools.
Select lab scope.
Select Live Data.
Select 12 volt square wave.
Press F2 for Scope.
Press F2 and use the down arrow to set voltage range to 20 volts. Press F2 again
when complete.
Connect the Black lead to the chassis ground. Connect the Red lead to the PCI Bus
circuit in the ACM connector.
Observe the voltage display on the DRB Lab Scope.
Does the voltage pulse from 0 to approximately 7.5 volts?
All
Yes → Go To 4
No → Repair the PCI Bus circuit for an open.
Perform AIRBAG VERIFICATION TEST - VER 1.
4 If there are no possible causes remaining, view repair. All
Repair
Replace the Airbag Control Module (ACM) in accordance with the
Service lnformation. WARNING: To avoid personal injury or
death, make sure the battery is disconnected and wait 2 minutes
before proceeding.
Perform AIRBAG VERIFICATION TEST - VER 1.
100
COMMUNICATION
*NO RESPONSE FROM ACM — Continued
To Next Page
