Symptom:
SEAT SQUIB SHORT TO BATTERY
When Monitored and Set Condition:
SEAT SQUIB SHORT TO BATTERY
When Monitored: When the ignition is on, the SIACM monitors the voltage of the Seat
Squib circuits.
Set Condition: When the SIACM detects high voltage on the Seat Squib circuits.
POSSIBLE CAUSES
SEAT AIRBAG SHORT TO BATTERY
SEAT SQUIB LINE 1 OR LINE 2 SHORTED TO BATTERY
SIACM, SEAT SQUIB SHORT TO BATTERY
STORED CODE OR INTERMITTENT CONDITION
ACTIVE CODE PRESENT
TEST ACTION APPLICABILITY
1 Turn the ignition on.
Ensure the battery is fully charged.
NOTE: For the purpose of this test, the AECM and ORC modules will be
referred to as an ACM.
SELECT ONE:
All
LEFT SIACM - ACTIVE DTC
Go To 2
LEFT SIACM - STORED DTC
Go To 4
RIGHT SIACM - ACTIVE DTC
Go To 2
RIGHT SIACM - STORED DTC
Go To 4
NOTE: When reconnecting Airbag system components, the ignition must be
turned off and the battery must be disconnected.
76
AIRBAG
